Panasonic PT-EZ590LE


Key features:

  • LAN control function
  • Long Range Remote Control (30m)
  • Low noise level (29 dB in Eco mode)
  • Lamp replacement cycle up to 5000 hours
  • Keystone correction and curved projection
  • Dust-proof, rugged housing with a one-way airflow



The Panasonic PT-EZ590LE offers with its widescreen WUXGA resolution high-definition pictures. The brightness is high at 5,400 ANSI lumens, and the dynamic contrasts 10,000: 1. If you want to project in environments with daylight, the Daylight View Basic function is ideal. The special DICOM simulation mode has implemented for medical presentations. The Digital Link function (HDBaseT) transmits uncompressed Full HD videos, audio signals, and control commands over long distances via a single cable. It offers the inclusion of optional optics.



The projector can install using the remote-controlled lens shift, zoom, and focus. The Lens Shift Function has a vertical value of +/- 60% and a horizontal value of +/- 30%. In addition, the optional lenses offer another possibility to adapt the projector to the spatial conditions.


Image Technology

The Panasonic PT-EZ590LE offers the WUXGA resolution with the 1920 x 1200 pixels. The high-resolution widescreen Panasonic PT-EZ590LE projector has a light brightness of 5,400 ANSI lumens with a dynamic contrast ratio of 10,000: 1. The integrated Daylight View Basic function ensures bright projections despite daylight environments. A color adjustment function for correcting deviations in color reproduction in multiple projections and the DICOM simulation mode for medical presentations integrated.

Panasonic’s Daylight View Basic technology ensures images are clear and pleasing to view with enhanced detail, especially in dark areas of the usually tricky image in a bright room. A built-in sensor measures ambient light levels, while Daylight View Basic adjusts color raster and brightness based on ambient light levels. Coordinating Colors for Multi-Screen Projection corrects minor changes in the color range of individual devices configured for multi-screen projection, mainly when using the Side-by-side configuration.


Control & Connection

Building on HDBaseT, digital link technology enables the transmission of uncompressed Full HD video and Ethernet / RS-232C control commands over a single cable for distances of up to 100 meters. The technology simplifies installation, especially when the projector integrated into an existing network or control system. With its diverse connections, the Panasonic PT-EZ590LE conveniently positioned. It has the following interfaces: 2 xHDMI in, D-sub 15pin in and out, 5 x BNC RGBHV in, Cinch Video in, Cinch Stereo in, mini-jack audio and out, USB Type-A in, RS232C Din 9 pin in, and RJ45 with DIGITAL LINK in. Simple remote operation ensured via LAN.
